Best Sellers 2022 Fiber Pulse 3 In 1 Handheld Rust Removal Laser Cleaning Machine For Metal Mark

Views: 2     Author: hu     Publish Time: 2022-11-08      Origin: dapeng

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Description
New Type Portable 3 IN 1 1KW 1.5KW 2KW Multifunction Metal Laser Rust Remover Handheld Fiber Cleaning Welding Cutting Machine
Specification：
Model
DPH-1000-HL
DPH-1500-HL
DPH-2000-HL
Laser source type
Fiber source
Fiber source
Fiber source
Function
3 IN 1 Handheld Fiber Laser Cleaning Welding Cutting Machine
Laser Out Power
1000W
1500W
2000W
Laser wavelength
1070nm
1070nm
1070nm
Laser Source
Raycus/Max/IPG/nLIGHT
Raycus/Max/IPG/nLIGHT
Raycus/Max/IPG/nLIGHT
Focal spot diameter
0.1-3mm
0.1-3mm
0.1-3mm
Laser frequency
1-50Hz
1-50Hz
1-50Hz
Repeatability
±0.01mm
±0.01mm
±0.01mm
Machine operating temperature
0~40℃
0~40℃
0~40℃
Electricity demand
220V
220V
220V/380V
Cooling method
Water Chiller Hanli
Water Chiller Hanli
Water Chiller Hanli
Continuous operating time
24 hours
24 hours
24 hours
Weight
230kg
230kg
230kg
Dimensions
100*100*172cm
100*100*172cm
100*100*172cm
Laser control system
Depeng Touch screen
Depeng Touch screen
Depeng Touch screen
Features:
Handheld Fiber Laser Cleaning&Welding&Cutting Machine Description
The laser cleaning and welding machine can not only clean the metal surface contaminants, but also weld and combine various metal materials.
It is a mlti-functinal laser equipment. Equipped with Ruida system, it has two modes of cleaning and welding, which can be flexibly switched.
1. Fast and concentrated pulses with enormous power impact and gasification of residues on the surface;
2. Laser pulses are verysuitable for the removal of organic matter, such as residues in the tire mold fouling;
3. The impact of a short period of timewill not cause metal surface heating, no damage to the substrate.
4. Clean or remove the surface paint layer quickly and cleanly;
5. Accurate cleaning and paint removal effect;
6. No damage to the base material.
Cleaning
Fiber laser cleaning head has a good cleaning effect on iron, carbon steel plate, stainless steel plate, mold steel gear, aluminum plate, paint layer and other materials. The laser cleaning mode can clean the oxide layer, remove the paint on the surface, clean the surface oil, stains and dit, clean the rubber mold residue.
Meet the requirements for equipment cleaning in the shipbuilding industry, auto parts, rubber molds, machine tools, environmental protection industries and other fields.
Welding
Fiber laser welding head is suitable for stainless steel, copper, aluminum, gold, chromium, nickel and other metals or alloys It can also be used for a varies of welding between different material, such as copper - brass,  titanium gold, nickel - copper and so on. Meet the welding needs of kitchen cabinets, stair elevators, shelves, ovens, stainless steel door and window guardrails, craft gifts, home furnishing and other industries.
