| Model | SJ-01 | SJ-02 | SJ-03 | SJ-04 |
| Laser source type | Fiber source | Fiber source | Fiber source | Fiber source |
| Laser Out Power | 20W | 30W | 50W | 100W |
| Laser wavelength | 1064nm | 1064nm | 1064nm | 1064nm |
| Laser Source | Raycus/Max/IPG | Raycus/Max/IPG | Raycus/Max/IPG | Raycus/Max/IPG |
| Optional Marking Area | 150mm*150mm,180mm*180mm,200mm*200mm,300mm*300mm | 150mm*150mm,180mm*180mm,200mm*200mm,300mm*300mm | 150mm*150mm,180mm*180mm,200mm*200mm,300mm*300mm | 150mm*150mm,180mm*180mm,200mm*200mm,300mm*300mm |
| Laser frequency | <0.6KW | <0.6KW | <0.6KW | <0.6KW |
| Repeatability | ±0.002mm | ±0.002mm | ±0.002mm | ±0.002mm |
| Machine operating temperature | 0~40℃ | 0~40℃ | 0~40℃ | 0~40℃ |
| Electricity demand | Ac220V±10%. 50HZ.5Amp | Ac220V±10%. 50HZ.5Amp | Ac220V±10%. 50HZ.5Amp | Ac220V±10%. 50HZ.5Amp |
| Cooling method | Air cooled | Air cooled | Air cooled | Air cooled |
| Continuous operating time | 24 hours | 24 hours | 24 hours | 24 hours |
| Weight | 130kg | 130kg | 130kg | 130kg |
| Dimensions | 80*65*142cm | 80*65*142cm | 80*65*142cm | 80*65*142cm |
| Software | EZCAD | EZCAD | EZCAD | EZCAD |
| True Type Fonts | Single Stroke Fonts | Elliptical Text | ||
| Sequential Serial Numbers | Customizable Auto Dating | Barcodes | ||
| QR Codes and Data Matrix | UID Wizard | Logo | ||
| Photo Quality Images - JPG, TIF, GIF | Corel Draw, Adobe Illustrator | Raster Graphics | ||
| Vector Graphics | CAD Files | |||
| Metal Industry, Jewelry Factories, Hardware Tools, Electronics Components, Auto Parts, Mobile & Accessories, Clock&Watches,Planting Coating Materials, Spray Material, Plastic, Spectacles,etc. | ||||
| Stainless Steel | Steel | Aluminum, Carbide | ||
| Nickel | Titanium | Cast Iron | ||
| Chrome | Painted Metal Alloys | Multi-Coated Metals | ||
| Plastics/Rubber | Backlit Buttons | Polycarbonate | ||
| PVC | Composites | Many more materials | ||
