G-1400
The G-1400 Large-Format Machining Center is engineered for large-scale precision machining, heavy-duty metal cutting, and complex multi-surface manufacturing. Designed with a robust machine structure, high-torque spindle, and precision 5-axis rotary table, it delivers exceptional rigidity, machining accuracy, and productivity for oversized and high-value components.
Featuring 1,400 mm X-axis travel, 1,400 mm Y-axis travel, 900 mm Z-axis travel, a 1,200 mm rotary table, and a 2,000 kg maximum table load, the G-1400 is capable of machining large workpieces with superior stability and precision. It is an ideal solution for aerospace, energy, mold & die, heavy equipment, automotive, and industrial manufacturing.
The G-1400 combines large-format machining capability, high-rigidity construction, and simultaneous 5-axis technology to handle oversized and complex components with maximum efficiency. By completing multi-face machining in a single setup, manufacturers can significantly reduce setup time, improve dimensional accuracy, and increase overall production efficiency.
Large-Format 5-Axis Machining Center
1,200 mm Precision Rotary Table
2,000 kg Maximum Table Load
High-Power HSK-A63 Spindle
Heavy-Duty Machine Construction
Simultaneous 5-Axis Machining
Large Travel for Oversized Components
High-Torque Cutting Performance
Precision Ball Screw Drive System
Heavy-Duty Roller Linear Guideways
Intelligent CNC Control System
Automatic Tool Changer (ATC)
Excellent Thermal Stability
High Positioning Accuracy
Efficient Chip Management System
The G-1400 is designed for machining large and complex components across multiple industries.
Aircraft structural components, landing gear parts, engine casings, turbine housings, aerospace fixtures, and titanium alloy components.
Wind power equipment, oil & gas components, valve bodies, pump housings, compressor parts, and power generation equipment.
Large injection molds, die-casting molds, automotive molds, stamping dies, and precision tooling.
Construction machinery, mining equipment, hydraulic components, gearbox housings, and heavy industrial machinery.
Large structural parts, battery trays, chassis components, transmission housings, and electric vehicle manufacturing.
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
Table Size | 320 | 400 | 500 | 630 | 1200 | mm |
A-Axis Tilting Angle | ±110 | ±110 | ±110 | ±110 | ±110 | ° |
C-Axis Rotation Angle | 360 | 360 | 360 | 360 | 360 | ° |
A-Axis Rotation Speed | 100 | 100 | 80 | 80 | 50 | rpm |
C-Axis Rotation Speed | 200 | 200 | 120 | 120 | 100 | rpm |
Max Table Load | 100 | 250 | 450 | 850 | 2000 | kg |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
X-Axis Travel | 400 | 500 | 600 | 800 | 1400 | mm |
Y-Axis Travel | 600 | 650 | 800 | 900 | 1400 | mm |
Z-Axis Travel | 350 | 450 | 480 | 600 | 900 | mm |
90° Y Front Travel | 350 | 400 | 450 | 550 | 750 | mm |
Spindle Nose to Table Surface | 470 | 570 | 630 | 720 | 1020 | mm |
Clearance | 120 | 120 | 90 | 120 | 120 | mm |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
Taper Type | HSKE40 / E50 / A63 | HSK A63 | HSK A63 | HSK A63 | HSK A63 | — |
Speed Range | 30,000 | 20,000 | 20,000 | 20,000 | 20,000 | rpm |
Spindle Power | 9 | 20 | 35 | 45 | 45 | kW |
Rated Torque | 14 | 33 | 48 | 100 | 100 | Nm |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
Rapid Traverse (X/Y/Z) | 30 | 36 | 36 | 36 | 24 | m/min |
Ball Screw Spec | 3210/3210/3210 | 3212/4012/3212 | 4012/5012/4012 | 4012/5512/4012 | 4012/5512/4012 | — |
Linear Guideways | 35/35/35 | 35/45/35 | 35×2 / 45×4 / 35×2 | 45/45/45 | 45/55/45 | — |
Servo Motor Torque | 20/30/20 | 25/35/25 | 30/35/30 | 30/35/30 | 35/45/35 | N·m |
Feed Rate (X/Y/Z) | 15 | 15 | 15 | 15 | 15 | m/min |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
Tool Holder Type | HSKE40 | HSK A63 | HSK A63 | HSK A63 | HSK A63 | — |
Tool Selection Method | Bi-directional shortest path selection | Same | Same | Same | Same | — |
Tool Capacity | 20 / 18 | 32 | 32 / 48 | 32 / 48 | 32 / 48 | tools |
Max Tool Length | 100 | 300 | 300 | 300 | 300 | mm |
Max Tool Weight | 3 | 8 | 8 | 8 | 10 | kg |
Max Tool Diameter (full tool) | Ø50 | Ø70 | Ø70 | Ø70 | Ø70 | mm |
Max Tool Diameter (adjacent empty slot) | Ø65 | Ø120 | Ø120 | Ø120 | Ø125 | mm |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
X/Y/Z (300mm) | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | mm |
A-Axis | ±5 | ±5 | ±5 | ±5 | ±5 | arc-sec |
C-Axis | ±5 | ±5 | ±5 | ±5 | ±5 | arc-sec |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
X/Y/Z (300mm) | 0.003 | 0.003 | 0.003 | 0.003 | 0.003 | mm |
A-Axis | <4 | <4 | <4 | <4 | <4 | arc-sec |
C-Axis | <4 | <4 | <4 | <4 | <4 | arc-sec |
Item | G-400 | G-500 | G-630 | G-800 | G-1400 | Unit |
|---|---|---|---|---|---|---|
Machine Weight | 4,800 | 9,500 | 13,000 | 17,000 | 26,000 | kg |
Machine Dimensions (L×W×H, excl. chip conveyor) | 2200×2900×2300 | 2700×3500×2900 | 2960×4200×3350 | 3300×4600×3600 | 4500×5500×4000 | mm |
The G-500 adopts premium mechanical and electrical components to ensure long-term machining accuracy and operational reliability.
High-Speed Built-in Spindle
Precision A/C Rotary Table
High-Precision Ball Screws
Roller Linear Guideways
Automatic Tool Changer (ATC)
High-Performance Servo Motors
Intelligent CNC Controller
Automatic Lubrication System
Efficient Cooling System
High-Power HSK-A63 Built-in Spindle
Precision A/C Rotary Table
Heavy-Duty Ball Screw Drive System
Roller Linear Guideways
Automatic Tool Changer (ATC)
High-Performance Servo Motors
Advanced CNC Control System
Automatic Lubrication System
Intelligent Cooling System
The 1,400 × 1,400 × 900 mm working envelope allows efficient machining of oversized and complex components.
The 45 kW spindle, 100 Nm torque, and 2,000 kg table capacity provide outstanding performance for demanding cutting applications.
Precision rotary axes, high-quality ball screws, and rigid guideway systems ensure excellent positioning accuracy and repeatability.
Simultaneous 5-axis machining reduces multiple setups, shortens machining cycles, and improves production efficiency.
Designed for continuous heavy-duty operation, the G-1400 offers long-term stability, durability, and consistent machining quality.
Renishaw Workpiece Probe
Automatic Tool Setter
Through-Spindle Coolant (TSC)
Chip Conveyor
Oil Mist Collector
Automatic Door System
Rotary Scale Feedback
Tool Monitoring System
High-Speed Spindle Upgrade
Robotic Automation Interface
Aerospace Manufacturing
Energy Equipment
Automotive Manufacturing
Mold & Die Industry
Heavy Equipment
Precision Engineering
Industrial Machinery
Automation Equipment
