FL-A100
The 100W Handheld and Portable Laser Cleaning Machine is designed for manual surface cleaning applications, offering an efficient, precise, and environmentally friendly solution for metal treatment.
This machine adopts pulsed fiber laser technology, enabling non-contact cleaning without damaging the base material. It effectively removes rust, paint, oxide layers, oil stains, and surface contaminants, making it ideal for restoration, maintenance, and surface preparation tasks.
With its compact and lightweight design, the handheld laser cleaner allows flexible operation in workshops, maintenance sites, and on-field applications. The air-cooled system ensures stable performance with low maintenance requirements, while multiple cleaning modes provide adjustable cleaning intensity for different materials and surface conditions.
Compared with traditional mechanical or chemical cleaning methods, laser cleaning delivers high precision, no consumables, no chemical pollution, and minimal material loss, significantly improving cleaning efficiency and safety.
The 100W Handheld Laser Rust Removal Machine is designed for precise and efficient surface cleaning of metal materials.
By using high-energy pulsed fiber laser technology, the machine removes contaminants through laser ablation without physical contact or damage to the substrate.
Effectively removes surface rust and light to medium corrosion from steel, stainless steel, and iron parts.
The laser selectively vaporizes the rust layer while preserving the original metal surface.
Removes oxide layers formed during welding, heat treatment, or long-term exposure to air.
Ideal for restoring metal surfaces before further processing.
Capable of removing thin paint layers, coatings, and surface residues.
Suitable for localized cleaning and surface repair work.
Efficiently cleans oil stains, grease, and organic contaminants from metal surfaces, improving adhesion for subsequent processes such as welding or coating.
Prepares metal surfaces before welding, painting, plating, or bonding by ensuring a clean and activated surface without chemical residue.
The laser cleaning process is non-contact, non-abrasive, and environmentally friendly.
No chemicals, no consumables, and no secondary pollution are generated during operation.
| Item | FL-A50 | FL-A100 | FL-A200 | FL-A300 |
|---|---|---|---|---|
| Model | FL-A50 | FL-A100 | FL-A200 | FL-A300 |
| Rated Voltage | 220V~ | 220V~ | 220V~ | 220V~ |
| Rated Frequency | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz |
| Total Power | 300 W | 500 W | 1000 W | 1500 W |
| Laser Power | 50 W | 100 W | 200 W | 300 W |
| Laser Class | Class 4 | Class 4 | Class 4 | Class 4 |
| Laser Wavelength | 1064 nm | 1064 nm | 1064 nm | 1064 nm |
| Cooling Mode | Air Cooling | Air Cooling | Air Cooling | Air Cooling |
| Cleaning Modes | 6 | 6 | 6 | 6 |
| Max. Scanning Width | 100 mm | 100 mm | 100 mm | 100 mm |
| Optical Fiber Length | 3 m | 3 m | 5 m | 5 m |
| Overall Dimensions (L×W×H) | 530 × 295 × 411 mm | 530 × 295 × 411 mm | 530 × 295 × 461 mm | 530 × 295 × 461 mm |
Rust removal for steel and stainless steel parts
Cleaning of metal sheets, pipes, and structural components
Cleaning of automotive parts and components
Removal of rust, oil, and coatings before assembly or repair
Cleaning of molds without damaging precision surfaces
Removal of residues, rust, and release agents
Rust and contamination removal for mechanical parts
Maintenance of machinery and industrial equipment
Cleaning before welding to improve weld quality
Removal of oxide layers and discoloration after welding
Handheld and lightweight design makes it suitable for on-site maintenance, workshops, and field operations
