FL-E300
The 300W air-cooled portable pulsed laser cleaning machine is a high-efficiency laser cleaning solution specially designed for shoe mold cleaning and maintenance.
With a compact, portable structure and air-cooling system, the machine does not require a water chiller, making it ideal for on-site mold cleaning and flexible factory use.
The high-power 300W pulsed laser effectively removes rubber residues, carbon deposits, oil, oxidation layers, and light rust from shoe molds, while preserving fine mold textures and engraving details without causing damage.
300W pulsed laser power for efficient mold cleaning
Air-cooled design, no water cooling system required
Portable structure, easy to move and operate
Non-contact & non-abrasive cleaning, no mold wear
Maintains mold surface accuracy and details
Eco-friendly process, no chemicals or consumables
Shoe mold cleaning
Rubber mold and sole mold cleaning
Injection mold maintenance
Mold refurbishment and routine maintenance
Mold steel
Stainless steel molds
Aluminum shoe molds
Tool steel
The 300W air-cooled portable pulsed laser cleaning machine is an ideal solution for shoe mold cleaning, combining high power, portability, and precision cleaning.
It helps reduce manual cleaning time, extend mold service life, and improve production efficiency in the footwear industry.
| No. | Item | FL-E100 | FL-E200 | FL-E300 |
|---|---|---|---|---|
| 1 | Model | FL-E100 | FL-E200 | FL-E300 |
| 2 | Rated Voltage | 220V AC | 220V AC | 220V AC |
| 3 | Rated Frequency | 50 / 60 Hz | 50 / 60 Hz | 50 / 60 Hz |
| 4 | Input Power | 500 W | 1000 W | 1500 W |
| 5 | Laser Power | 100 W | 200 W | 300 W |
| 6 | Laser Class | Class 4 | Class 4 | Class 4 |
| 7 | Laser Wavelength | 1064 nm | 1064 nm | 1064 nm |
| 8 | Cooling Mode | Air Cooling | Air Cooling | Air Cooling |
| 9 | Cleaning Modes | 6 Modes | 6 Modes | 6 Modes |
| 10 | Max. Scanning Width | 100 mm | 100 mm | 100 mm |
| 11 | Optical Fiber Length | 3 m | 5 m | 5 m |
| 12 | Overall Dimensions (L×W×H) | 530×295×411 mm | 530×295×461 mm | 530×295×461 mm |
The FL-E series air-cooled pulsed laser cleaning machines include 100W, 200W, and 300W models, designed for metal rust removal, mold cleaning, oil and grease cleaning, and surface residue removal.
All models operate on 220V AC, 50/60Hz, feature 1064nm pulsed fiber laser technology, and are equipped with an air-cooling system, eliminating the need for an external water chiller.
With 6 adjustable cleaning modes and a maximum scanning width of 100 mm, the FL-E series offers precise, flexible, and efficient cleaning for various industrial applications.
The compact design and optional fiber lengths make these machines ideal for on-site cleaning, maintenance work, and industrial mold servicing.
