HN-QX300(Y)
Portable | High-Precision | Maintenance-Free | Industrial-Grade
The 300W Air-Cooled Laser Cleaning Machine is a compact and efficient rust, paint, and oxide removal solution using advanced pulsed fiber laser technology. Featuring forced air cooling (no water chiller needed), 6 selectable cleaning modes, and a 100mm working width, it offers non-contact, eco-friendly surface cleaning ideal for metal, molds, and industrial parts. With optional battery packs, it's fully portable for on-site or field operations.
| Feature | Specification |
|---|---|
| Laser Power | 300W (Pulsed) |
| Laser Wavelength | 1064nm |
| Laser Class | Class 4 |
| Cleaning Width | 100mm |
| Cleaning Modes | 6 selectable modes |
| Cooling Method | Forced air cooling |
| Input Power Supply | AC110–220V |
| Machine Power Consumption | 1000W |
| Fiber Cable Length | 5 meters |
| Dimensions (L × W × H) | 370 × 205 × 390 mm |
| Weight | 13.5 kg |
Laser Power: 300W (Pulsed)
Cooling: Air-cooled – no chiller required
Cleaning Width: 100mm
Modes: 6 cleaning patterns
Power Supply: AC110–220V
Machine Weight: 13.5kg
Optional Battery Runtime: 1–2 hours
| Model | DC-24 | DC-42 |
|---|---|---|
| Capacity | 23.4Ah | 41.6Ah |
| Voltage | DC60V | DC60V |
| Current | 20A | 20A |
| Runtime | Approx. 1 hour | Approx. 2 hours |
| Weight | 15 kg | 22 kg |
| Dimensions (L × W × H) | 373 × 276 × 150 mm | 458 × 347 × 204 mm |
The 300W Air-Cooled Laser Cleaning Machine is designed for maximum mobility, ease of use, and on-site flexibility, making it ideal for industrial maintenance, fieldwork, and remote operations. Here’s what makes it truly convenient:
Weighs only 13.5 kg, making it easy for a single operator to carry or transport.
Small footprint (370 × 205 × 390 mm) fits in tight spaces like work trucks, mobile service units, and factory lines.
Equipped with advanced forced air cooling, it eliminates the bulk and maintenance of traditional water-cooling systems.
Simply plug in and start — reduces setup time.
Universal power input (AC110–220V) works in various regions and environments.
Quick startup, minimal operator training needed.
Add-on DC60V battery modules allow completely cordless operation.
Run time up to 2 hours, perfect for outdoor or hard-to-reach areas without electricity.
Extended fiber cable gives operators freedom to reach complex surfaces without moving the base unit frequently.
