RRP1300
✅ Wide Working Width: 1300mm (51 inches), ideal for large plates and a wide range of metal workpieces.
✅ Wet Sanding System: Integrated water cooling system effectively reduces heat during grinding, prevents discoloration, suppresses dust, and improves surface quality.
✅ Powerful Multi-Head Configuration: Equipped with multiple abrasive belt stations, optional rotary brush heads, and adjustable pressure rollers, achieving multi-process treatment in a single pass.
✅ Heavy-Duty Conveyor Feeding System: Stable feeding via a durable conveyor belt with adjustable speed (0.5~6m/min), suitable for continuous production environments.
✅ High-Power Drive Motors: Strong motor capacity (up to 30-40kW per station) ensures aggressive material removal when needed.
✅ Precision Workpiece Control: Servo-controlled thickness adjustment for easy setup and high accuracy (±0.01mm).
✅ Enhanced Safety & Cleanliness: Wet operation eliminates airborne dust and reduces fire risk while improving operator safety.
Heavy slag removal for flame-cut, plasma-cut, and laser-cut parts.
Oxide layer removal from hot-rolled steel.
Deburring of sharp edges and edge rounding (up to R2 radius).
Fine brushing and polishing of stainless steel, aluminum, carbon steel, and non-ferrous metals.
Consistent surface preparation before painting, coating, or welding.
| Specification | Unit | RRP1300 |
|---|---|---|
| Max Working Width | mm | 1300 |
| Working Thickness | mm | 0.8 - 80 |
| Minimum Workpiece Size | mm | 50 × 50 |
| Conveyor Speed | m/min | 0.5 – 6 (variable) |
| Abrasive Belt Size | mm | 1910 × 1300 |
| Brush Roller Diameter | mm | 300 |
| Main Drive Motor Power | kW | 22-30kW (per station) |
| Total Power | kW | 45-55 kW |
| Number of Sanding Stations | - | 2-3 (customizable) |
| Cooling System | - | Wet sanding with circulating water |
| Machine Weight | kg | ~4500 kg |
✅ All-in-One Processing: Achieve deburring, slag removal, edge rounding, and surface finishing in one machine.
✅ Cost-Efficient Wet Process: Lower consumable wear, better surface quality, and no overheating.
✅ Consistent, Repeatable Finish: Ensures product uniformity with reduced rework.
✅ Heavy-Duty Performance: Built for 24/7 industrial use in metal fabrication plants.
✅ Cleaner, Safer Operation: Wet process minimizes dust, sparks, and improves the working environment.
✅ Rotary planetary brush heads for complex edge rounding and hole deburring.
✅ Touchscreen PLC control with process memory and auto diagnostics.
✅ Vacuum conveyor for small part processing.
✅ Full enclosed cover for maximum environmental protection.
✅ Water filtration and recirculation unit for reduced water consumption.
