G120D/G170D/G240D
Fully automatic loading rack, saving time and labor, simple structure, easy operation.
Efficiency is 5-6 times that of ordinary tube cutting machines.
Minimal tail material blind zone, saving materials and reducing subsequent processes.
Cutting residual tail material length can be controlled arbitrarily, even to zero, greatly reducing material waste.
Follow-up cutting: Standard integrated height controller enables easy handling of deformed pipes.
Modular design, stable performance
Optical and electrical modules are separated internally for more stable operation.
Convenient maintenance, reduced downtime
Optical modules, electrical modules, control units, and drive units can be directly replaced, upgraded, and maintained at the customer site.
Customizable to meet diverse needs
Users can select different fiber core diameters to meet various processing requirements.
Uniform spot energy distribution for stable processing
Reduces welding spatter and improves thick plate cutting stability.
Versatile applications
Compatible with laser processing heads, galvanometers, and can be integrated with robots and machine tools for precision laser cutting and welding, widely used in 3C electronics, hardware, medical, automotive, and aerospace industries.
High adaptability:
Compatible with QBH and QCS fiber interfaces, ensuring compatibility with mainstream laser sources.
Superior design:
Optimized optical configuration and smooth, efficient airflow design significantly improve cutting quality and efficiency.
Slim nozzle design:
Modular, elongated nozzle design minimizes workpiece interference.
Compact structure:
Ultra-lightweight and compact, reducing robotic load requirements, improving cutting speed and quality.
BT220 Manual Focusing
LCN03A Manual Focusing
Developed in collaboration with top universities, tailored for the door and window railing industry.
Designed for laser tube cutting machines.
Functions as an independent rotating spindle, enabling quick clamping and release via side air intake.
High mechanical efficiency, minimal energy loss, strong and stable clamping force.
Direct cylinder output ensures a wide clamping range and easy software control.
Simple structure, lightweight, low failure rate, stable performance, low inertia, and energy efficiency.
Small axial size for lower zero-tail material costs.
Square bore design increases the range of square tube specifications compared to round bore chucks.
High-quality stainless steel water circulation pump with large flow, high head, low noise, and long lifespan.
Automatic control system:
Computer controller with CPU automatic control, simple and intuitive operation.
High control precision (±0.1°C), automatic fault diagnosis with direct display for quick troubleshooting.
Dual-temperature precision cooling:
Provides stable temperature control for the laser source and a separate cooling loop for lenses to prevent condensation damage.
| Model | G120D | G170D | G240D |
|---|---|---|---|
| Laser Power (W) | 1500-6000 | 1500-6000 | 1500-6000 |
| Cutting Diameter (mm) | Ø10-120, □10-120 | Ø10-170, □10-170 | Ø10-240, □10-240 |
| Repositioning Accuracy (mm) | ±0.02 | ±0.02 | ±0.02 |
| Tube Processing Range (mm) | ≈6250 | ≈6250 | ≈6250 |
| Machine Dimensions (mm) | 8856×1365×2172 | 8856×1365×2172 | 8856×1365×2172 |
| Machine + Rack Dimensions (mm) | Semi-auto: 8856×1876×2172 Full-auto: 8856×2886×2172 | Semi-auto: 8856×1876×2172 Full-auto: 8856×2886×2172 | Semi-auto: 8856×1876×2172 Full-auto: 8856×2886×2172 |
| Machine Weight (T) | ≈2.5 | ≈2.5 | ≈3.5 |
| Acceleration (G) | ≈1.6 | ≈1.3 | ≈1.0 |
| Tail Material Length (mm) | ≈50 | ≈80 | ≈100 |
Specifications are subject to change without prior notice. Final technical parameters are based on actual order agreements.
| No. | Item | Brand/Origin | Model/Specification | Quantity | Remarks |
|---|---|---|---|---|---|
| 1 | Fiber Laser Source | Chuangxin/Raycus | - | 1 Set | - |
| 2 | Fiber Laser Cutting Head | Jiaqiang/Osprey | - | 1 Set | - |
| 3 | Fiber Control System | Boci/Weihong/Fangling | - | 1 Set | - |
| 4 | Rotary Pneumatic Chuck | Byute/Others | - | 1 Set | - |
| 5 | X.Y.Z Axis Slide Rail | SHAC/AirTAC | - | 3 Sets | - |
| 6 | X.Y.Z Axis Guide Rail | SHAC/AirTAC | - | 3 Sets | - |
| 7 | X.Y Axis Rack | Taiwan Liangchi/Taiwan Jingte | - | 2 Sets | - |
| 8 | X.Y.Z.U Axis Servo Motor & Driver | Hechuan/Weichuang | - | 4-5 Sets | - |
| 9 | Pneumatic System | AirTAC | - | Various | - |
| 10 | Electrical Proportional Valve | AirTAC/SMC | - | 1 Pc | - |
| 11 | Machine Accessories | Standard | - | 1 Set | - |
| 12 | Machine Bed | Standard | - | 1 Unit | - |
| 13 | Control Cabinet | Standard | - | 1 Set | - |
| 14 | Circuit Breakers & Relays | Schneider/DELIXI | - | 1 Set | - |
| 15 | Power Supply | Schneider/DELIXI | - | 1 Set | - |
| 16 | Chiller Unit | Hanli | - | 1 Set | - |
| 17 | Loading System | Standard | - | 1 Set | - |
| No. | Item | Specification | Unit | Quantity | Remarks |
|---|---|---|---|---|---|
| 1 | Optical Lens | Jiaqiang/Osprey | Pc | 5 | - |
| 2 | Cutting Nozzle | Jiaqiang/Osprey | Pc | 5 | - |
| 3 | Ceramic Ring | Jiaqiang/Osprey | Pc | 5 | - |
Specifications are subject to change without prior notice. Final technical parameters are based on actual order agreements.
