3000W CNC Fiber Laser Tube Cutting Machine 2-Chuck for 250mm Tube Cutting

G25-7025B Fiber Laser Tube Cutting Machine (3000W)

Model: G25-7025B
Laser Power: 3000W

Product Application Range

• Pipe Types: Compatible with round pipes, square pipes, rectangular pipes, elliptical pipes, I-beams, U-beams, angle steel, and other profiles.

• Pipe Sizes:

• Round pipe: φ12 ~ 250mm

• Square pipe: 12 ~ 175mm

• Rectangular pipe: Max 200 x 120mm

• Industries:

• Steel Structures

• Aerospace

• Automotive Manufacturing

• Garden Machinery

• Agricultural Machinery

• Fitness Equipment

• Smart Home

• Electric Bike/Vehicle Manufacturing

• Escalator and Shelf Industries

• Pipe Processing for various sectors.

Key Components Configuration

Machine Specifications

• Machine Dimensions: 9600mm (L) x 3200mm (W) x 2800mm (H)

• Weight: 8.5 tons

• Power Consumption: 35-45KW

• Operating Temperature: 0-40°C

• Max Tube Length: 7000mm (Standard, customizable upon request)

Cutting Range and Parameters

• Cutting Range:

• Round Tube: φ12-248mm

• Square Tube: 12-175mm

• Rectangular Tube Max: 200x120mm

• Cutting Kerf: 0.1-0.2mm

• Speed & Acceleration:

• X/Y-axis: ±0.03mm/1000mm

• U-axis (rotation): ≤5 arc minutes

• U-axis max speed: 120 RPM

• X-axis: 100m/min

• Y-axis: 120m/min

• Max Acceleration: 1.2G

• Max Speed:

• Repeatability:

Key Features

• Automatic Feeding: Semi-automatic with an option for full automation, allowing for efficient tube feeding.

• Servo Floating Support: Includes support with a load capacity of up to 200kg per tube.

• Integrated Machine Frame: The bed structure is welded with pipe and heat-treated to ensure high rigidity and stability.

• CNC Control System: Features a high-performance Beichu CNC system, offering rapid interpolation and ease of operation.

• Unique Features:

• Automatic tube alignment for faster cutting.

• Supports various cutting processes like progressive drilling and pre-drilling.

• Automatic sorting and sequencing of cuts, reducing manual intervention.

Power, Water, and Gas Requirements

• Electric Power:

• Voltage: 380V ± 5%, 50Hz

• Requires a stable power supply and a minimum of 60KVA transformer.

• Cooling Water:

• 40L of deionized water (≤10 μS conductivity).

• Assist Gas:

• Oxygen: ≥99.6% purity, pressure 1 MPa, flow ≥1m³/min (for carbon steel cutting).

• Nitrogen: ≥99.99% purity, pressure 2.5 MPa, flow ≥2.5m³/min (for stainless steel and other non-ferrous cutting).

• Air: Pressure ≥1.3 MPa, flow ≥1.8m³/min.

Installation Environment

• Temperature: 5°C to 30°C

• Humidity: Less than 70%

• Foundation:

• The installation site must be level and free from strong vibrations.

• Ground strength must be adequate to support the machine.

Additional Information

• Control System:
  The CNC system utilizes Beichu for faster cutting operations, providing high efficiency and precision. It supports different cutting processes and assists with automatic path adjustments, ensuring optimal cutting conditions.

• Maintenance: The machine has self-diagnostics and protection functions, reducing downtime and improving reliability.
