CX08x665
The CX08x665 Universal Forming Machine is engineered for efficient, precise, and quiet cold forming of various metals and profiles without material removal (chipless). Designed for shrinking, stretching, doming, planishing, reforming, flattening, and straightening, it is ideal for manufacturing, restoration, and correction of metal parts.
This machine supports a wide range of materials including steel, aluminum, copper, and stainless steel, and is suitable for forming both large and small components.
| Specification | Value |
|---|---|
| Model | CX08x665 |
| Open Height (between upper & lower dies) | 210–295 mm |
| Ram Vibration Range | 8 mm |
| Ram Adjustable Feed Range | 80 mm |
| Ram Vibration Frequency | 0–600 strokes/min |
| Max Thickness (Steel, σb=450 MPa) | 6 mm |
| Max Thickness (Aluminum, σb=250 MPa) | 8 mm |
| Max Thickness (Copper, σb=250 MPa) | 8 mm |
| Max Thickness (Stainless Steel, σb=450 MPa) | 4 mm |
| Machine Weight | 2542 kg |
| Machine Dimensions (L × W × H) | 2580 × 1321 × 2400 mm |
Chipless cold forming: No material loss or thermal impact.
Multi-function forming: One machine, multiple applications.
Minimum noise and vibration: Operator-friendly and ideal for indoor workshops.
Adjustable settings: Ram stroke, vibration frequency, and feed range for maximum flexibility.
High durability: Robust design for industrial-grade use.
Automotive panel and frame manufacturing
Railway component fabrication
Vintage vehicle restoration
Precision repair and part correction
General metal fabrication workshops
