MSP-M800
The 800mm Automatic Deburring Machine is a high-performance industrial solution for metal sheet processing, designed to handle a variety of applications including deburring, edge rounding, polishing, and sanding. This versatile machine is ideal for processing different materials such as stainless steel, aluminum, carbon steel, and other non-ferrous metals.
Wide Processing Width
Accommodates metal sheets up to 800mm wide, suitable for medium to large-sized parts.
Multi-Purpose Functionality
Effectively removes burrs from edges and holes.
Rounds edges uniformly, achieving precise small R-arc finishes.
Polishes surfaces for a smooth, consistent finish.
Removes oxidation layers and laser-cut residue.
Advanced Processing Mechanism
Equipped with abrasive belts and universal sanding brushes that rotate and revolve simultaneously for comprehensive surface treatment.
Suitable for through-feed processing, ensuring high precision without compromising workpiece dimensions.
Ideal for laser-cut, CNC-punched, and stamped metal sheets, including those with protective films.
Efficient Dust Collection System
Wet dust collector captures grinding dust, reduces environmental impact, and ensures operator safety.
Metal powder residues are filtered for recycling, supporting eco-friendly production.
Adjustable Operation
Conveyor speed and brush rotation speed are adjustable through frequency converters, offering flexibility for different processing requirements.
High precision adjustments ensure uniform results for various workpiece thicknesses.
Industries: Automotive, aerospace, metal fabrication, construction, and more.
Processes: Stamping, shearing, laser cutting, plasma cutting, and flame cutting.
Materials: Stainless steel, aluminum, copper, carbon steel, and non-ferrous metals.
High Productivity: Continuous feeding for high processing volumes.
Superior Quality: Uniform, high-precision surface finishes outperform manual processing.
Cost Efficiency: Reduced operational costs and minimal consumable usage.
Eco-Friendly and Safe: Dust-free operation with effective filtration and recycling capabilities.
| Parameter | Specification |
|---|---|
| Processing Width | ≤780mm |
| Processing Thickness | 0.5~80mm |
| Minimum Workpiece Size | 50mm × 50mm |
| Machine Power | 22KW |
| Flap Brush Dimensions | Φ300mm × 300mm |
| Conveyor Speed | 0.5~6m/min (frequency adjustable) |
| Brush Rotation Speed | 8~26m/s (frequency adjustable) |
| Brush Revolution Speed | 1~15r/min (frequency adjustable) |
| Planetary Revolution Heads | 1 |
| Planetary Rotation Heads | 4 |
| Thickness Adjustment Accuracy | 0.01mm |
| Abrasive Material | Flap brush |
| Dust Extraction Volume | 3000m³/h |
| Machine Dimensions | 2350mm (L) × 1750mm (W) × 2150mm (H) |
| Machine Weight | Approx. 1.6T |
